JM Platemounted Fan

  • Volume flow up to 4.1 m3/s
  • Static pressures up to 175 Pa
  • 315mm to 630mm diameter
  • Suitable where low pressures and high air volumes are required
  • Fan performance is certified to ISO 5801
  • Operating temp. range : -40°C to +70°C as standard
  • JM plate-mounted fans come complete with diaphragm mounting plate
  • Overheat protection fitted as standard on 1ph
  • Motor protection IP55
  • Speed controllable
  • Supplied fully assembled
  • Inverter speed controllable
The JM axial plate fan with five impeller blades

Simple ventilation solution

  • Low pressure levels
  • High air volume
  • Mounting and connection flexibility

The Woods JM Platemounted fan features an aluminium adjustable fixed pitch impeller manufactured for greater performance. Available in sizes 315 to 630mm in diameter it is suitable where low pressures and high air volumes are required. Overheat protection is fitted as standard on 1 phase versions. Motor protection IP55. Speed controllable. Supplied fully assembled. Inverter speed controllable.

A simple ventilation option for building services, warehouses, factories, barns and other big industrial spaces. For a more powerful option, take a look at the Woods Plate Fan range.

Our JMP Axial Fan Product Range

PRODUCT REFERENCE EXAMPLE: 63JMP/20/4/3/24

  • 63 - denotes the fan impeller diameter in centimetres
  • JMP - denotes fan type
  • 20 - denotes impeller hub diameter in centimetres
  • 4 - denotes a nominal 4 pole speed
  • 3 - denotes the number of blades
  • 24 - denotes the pitch angle for the required duty
EP315412 PLT MTD 31JMP/16/4/5/30 1PH BT5
EP455410 PLT MTD 45JMP/16/4/5/24 1PH BT9
EP455430 PLT MTD 45JMP/16/4/5/32 3PH BT9
EP505415 PLT MTD 50JMP/20 /4/6/24 1PH CT5
EP505430 PLT MTD 50JMP/20/4/6/32 3PH CT9
EP635411 PLT MTD 63JMP/20/4/3/24 1PH CT9
EP635430 PLT MTD 63JMP/20/4/3/32 3PH D90



Product Selection

Documents

  • Axial Fan O&M Manual
